Drive System

Belt Drive

Motor

DC Motor

Speed

33 1/3 RPM, 45 RPM

Rotation Speed Variation

±2%

Wow and Flutter

0.20%

Signal-to-Noise Ratio

67dB or higher (A-weighted, 20kHz LPF) 60dB or higher (unweighted, 20kHz LPF)

Platter

Aluminum Die-cast

Diameter of Platter

12", 300mm

Tonearm section

Alumi tube

Type

Static Balance, Straight

Effective Arm Length

8.8", 223.6mm

Stylus Pressure Range

0 to 4g

Supported Cartridge Weight

3.5 to 6.0g

Overhang

18.6mm

Anti-skating Adjustment

Supported

Cartridge section

-

Type

MM type (Audio-Technica AT3600)

Stylus Construction

Bonded Diamond

Frequency Response

20Hz to 20kHz

Channel Separation

>18dB

Channel Balance

2.5dB

Vertical Tracking Angle

20 degrees

Supported Load Impedance

47k ohms

Output Voltage

2.5mV (1kHz, 3.54cm/sec.)

Stylus Pressure

3.5g ±0.5g

Cartridge Weight

5g ±0.5g

Head-shell Weight

10g (including Screws, Nuts and Wires)

Analog Output

-

Connector

RCA Pin jack (Gold-plated)

Power

AC 100 to 240V, 50/60Hz

Power Consumption

1.5W (less than 0.5W at Standby)

Overall Dimensions (W x H x D)

420 x 355x 121mm

Weight

Approx. 3.9 kg

Colors

‍White High Gloss / Black High Gloss
